Specifications
GPU memory 8GB GDDR6
Memory interface 128-bit
Memory bandwidth 192GB/s
NVIDIA Ampere-based CUDA® Cores 2,304
NVIDIA third-generation Tensor Cores 72
NVIDIA second-generation RT Cores 18
Single-precision performance 6.7 TFLOPS2
RT Core performance 13.2 TFLOPS2
Tensor performance 53.8 TFLOPS3
System interface PCle 4.0 x84
Power consumption Total board power: 50W
Thermal solution Active
Form factor 2.7” H x 6.4” L, single slot
Display connectors 4x Mini DisplayPort 1.4a
Max simultaneous displays 4x 4096 x 2160 @ 120Hz
4x 5120 x 2880 @ 60Hz
2x 7680 x 4320 @ 30Hz
Encode/decode engines 1x encode, 2x decode (+AV1 decode)
Graphics APIs DirectX 12, Shader Model 6.6,
OpenGL 4.65, Vulkan 1.35
Compute APIs CUDA 11.6, OpenCL 3.0,
DirectCompute
