- Wireless Standards
-
-
IEEE 802.11 b/g/n
-
- Frequency
-
-
2.4-2.5 GHz
-
- WiFi Speeds
-
-
• 11n: Up to 300Mbps (Dynamic)
• 11g: Up to 54Mbps (Dynamic)
• 11b: Up to 11Mbps (Dynamic)
-
- Reception Sensitivity
-
-
• 270M: -70dBm@10% PER • 11M: -87dBm@10% PER
• 130M: -72dBm@10% PER • 6 M: -92dBm@10% PER
• 54M: -74dBm@10% PER • 1 M: -94dBm@10% PER
-
- Transmission Power
-
-
<20dBm (EIRP)
-
- Wireless Security
-
-
WPA-PSK/WPA2-PSK
-
- Wireless Functions
-
-
Enable/Disable Wireless Radio, WDS Bridging
- WAN Type
-
-
Dynamic IP/Static IP/PPPoE/PPTP/L2TP
-
- Management
-
-
Access Control
Local Management
Remote Management
-
- DHCP
-
-
DHCP Server, DHCP Client List
-
- Port Forwarding
-
-
Virtual Server, UPnP, DMZ
-
- Firewall Security
-
-
IP and MAC Address Binding
-
- Guest Network
-
-
2.4GHz Guest Network
- Dimensions
-
-
5.8 × 4.5 × 1.3 in (147 × 115 × 34 mm)
-
- Button
-
-
RESET/WPS Button
-
- External Power Supply
-
-
5V/0.6A
-
- Antenna Type
-
-
3* Fixed Antennas
-
- Ethernet Ports
-
-
1* 10/100Mbps WAN Port,
3* 10/100Mbps LAN Ports
- Package Contents
-
-
Wi-Fi N Router (MW306R)
Power Adapter
Quick Installation Guide
Ethernet Cable
-
- Environment
-
-
• Operating Temperature: 0°C~40°C (32°F~104°F)
• Operating Humidity: 10%~90% Non-Condensing
