| External Power Supply |
5VDC/0.6A |
| Antenna Type |
4 x 5dBi fixed omni directional antennas |
| Signal Rate |
11n: Up to 300Mbps (Dynamic)
11g: Up to 54Mbps (Dynamic)
11b: Up to 11Mbps (Dynamic) |
| Button |
Reset button |
| Wireless Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Frequency |
2.4 - 2.5GHz |
| Reception Sensitivity |
270M: -70dBm@10% PER
130M: -72dBm@10% PER
54M: -74dBm@10% PER
11M: -87dBm@10% PER
6M: -92dBm@10% PER
1M: -94dBm@10% PER |
| Interfaces |
3 10/100Mbps LAN ports
1 10/100Mbps WAN port |
| Certifications |
CE, ROHS |
| Package Contents |
300Mbps Enhanced Wireless N Router
MW325R
Power adapter
Quick installation guide
RJ45 Ethernet cable
|
| Environment |
Operating temperature: 0°C ~ 40°C (32°F ~ 104°F)
Storage temperature: -40°C ~ 70°C (-40°F ~ 158°F)
Operating humidity: 10% ~ 90%, non-condensing
Storage humidity: 5% ~ 90%, non-condensing |
| Transmission Power |
<20dBm |
| Wireless Security |
WPA-PSK / WPA2-PSK |
| Wireless Functions |
Enable/Disable Wireless Radio, WDS Bridge
|
| WAN Type |
Dynamic IP/Static IP/PPPoE/L2TP/PPTP
|
| Management |
Access control
Local management
Remote management |
| DHCP |
Server, DHCP Client List
|
| Port Forwarding |
Virtual server, UPnP, DMZ |
| Dynamic DNS |
Oray |
| Firewall Security |
IP and MAC address binding |
| Protocols |
IPv4 |
| Guest Network |
2.4GHz guest network |
| Dimensions (W X D X H) |
167 x 118 x 33 mm |
