| Ethernet Ports |
3*10/100Mbps LAN Ports
1*10/100Mbps WAN Port
|
| Button |
WPS/Reset Button
|
| External Power Supply |
9V/0.85A
|
| Dimensions (W X D X H) |
222 x 140 x 32 mm
|
| Antenna Type |
4 * 5dBi
|
| Package Contents |
• AC1200 Wireless Dual Band Router (AC12)
• Power Adapter
• Ethernet Cable
• Quick Installation Guide
|
| Wireless Standards |
IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz
|
| Frequency |
2.4 - 2.5GHz, 5.15 - 5.25GHz
|
| Signal Rate |
300Mbps at 2.4GHz, 867Mbps at 5GHz
|
| Reception Sensitivity |
5GHz
• 11a 6M: -92dBm
• 11a 54M: -75dBm
• 11ac 20M MCS8: -70dBm
• 11ac 40M MCS9: -64dBm
• 11ac 80M MCS9: -60dBm
2.4GHz
• 11g 6M: -95dBm
• 11g 54M: -77dBm
• 11n 20M MCS7: -74dBm
• 11n 40M MCS7: -71dBm
|
| Wireless Functions |
Enable/Disable Wireless Radio, Wireless Statistics
|
| Wireless Security |
WPA-PSK / WPA2-PSK
|
| WAN Type |
Dynamic IP/Static IP/PPPoE/L2TP/PPTP
|
| DHCP |
Server
|
| Port Forwarding |
Virtual Server, UPnP, DMZ
|
| Management |
Access Control
Local Management
Remote Management
|
| Firewall Security |
IP and MAC Address Binding
|
| Guest Network |
2.4GHz Guest Network, 5GHz Guest Network
|
| Environment |
• Operating Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -40°C~70°C (-40°F~158°F)
• Operating Humidity: 10%~90% Non-Condensing
• Storage Humidity: 5%~90% Non-Condensing
|
