Technical Specifications
General
Device Interfaces
- USB 2.0
- SIM slot (6-pin)
- microSD card slot (microSD card not included, supports up to 32 GB)
Broadband Wireless Support
- LTE/DC-HSPA+/HSPA/WCDMA
- GSM/GPRS/EDGE
Radio Frequency Bands
- LTE @ 2600/1800/800 Mhz
- UMTS @ 2100/900 Mh
- Quadband GSM/GPRS/EDGE
Data Rate1
- LTE: 3GPP Rel-9 FDD-LTE Cat.4
- Downlink: Up to 150 Mbps
- Uplink: Up to 50 Mbps
- DC-HSPA+
- Downlink: Up to 42 Mbps
- Uplink: Up to 5.76 Mbps
Bandwidth
- 1.4, 3, 5, 10, 15, 20 MHz
Minimum System Requirements
- Windows XP/Vista/7/8/10, Mac OS X 10.5 or higher
- 128 MB RAM or greater
- 50 MB available disk space
Functionality
LTE Output Power
Antenna
Status LED
- Green (blinking): Connected to LTE network
- Blue (blinking): Connected to 3G network
- Purple (blinking): Connected to 2G network
- Red (blinking): No service/device error
Plug and Play
- Built-in drivers and software; no CD-ROM required
Software Features
- Connection Manager
- Phonebook
- SMS messaging
- APN Manager
Physical
Dimensions
- 103 x 34 x 11.5 mm (4.06 x 1.34 x 0.45 inches)
Weight
Certifications
1 Data rates are theoretical. Data transfer rate depends on network capacity and signal strength. Please check regional mobile operators for 4G LTE/3G mobile Internet availability.
2 Compatible with Windows XP/Vista/7/8, Mac OS X 10.5 or higher
