Dimensions
86 x 46 x 33 mm (3.4 x 1.8 x 1.3")
Weight
100 g (3.5 oz)
Output Voltage
48V DC @ 0.32A
Rated Voltage
100—240V AC @ 50/60Hz
LAN Activity Indicator
—
Gigabit LAN Port
?
Remote Reset Capability
—
Reset Button
—
2-pair Powering
Pins 4, 5 (+) and 7, 8 (-)
AC Connector
IEC-320 C6
Clamping Protection
11V Data, 60V Power
Data In / PoE
RJ45 Shielded Socket
Input Current
500mA Max.
Inrush Current
<100A peak at 25°C
Efficiency
84.25+%
Switching Frequency
65 kHz
Output Ripple
200mV pp
Line Regulation
≤ 3%
Load Regulation
≤ 5%
Max. Surge Discharge
1500A (8/20 μs) power
Peak Pulse Current
36A (10/1000 μs) data
Response Time
<1 ns
Shunt Capacitance
<5 pF data
Surge Protection
Difference and common mode
Ambient Storage Temperature
-30 to 70°C (-22 to 158° F)
Ambient Operating Temperature
0 to 40° C (32 to 104° F)
Ambient Operating Humidity
10 to 95% noncondensing
NDAA Compliant
?
Certifications
CE, FCC, IC, UL, CCC
