| Interface |
• 9× 10/100/1000 Mbps RJ45 Ports
• 1× 1000 Mbps Combo SFP/RJ45 Port
• AUTO Negotiation
• AUTO MDI/MDIX |
| Network Media |
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• EIA/TIA-568 100? STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
• EIA/TIA-568 100? STP (maximum 100m)
• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
• EIA/TIA-568 100? STP (maximum 100m) |
| Fan Quantity |
Fanless |
| Physical Security Lock |
Yes |
| External Power Supply |
External Power Adapter (Output: 53.5VDC / 2.43A) |
| Packet Forwarding Rate |
14.88 Mpps |
| PoE Ports (RJ45) |
• Standard: 802.3 af/at compliant
• PoE Ports: Ports 1–8
• Power Supply: 123 W |
| Mac Address Table |
4K |
| Jumbo Frame |
16 KB |
| Switching Capacity |
20 Gbps |
| Dimensions ( W x D x H ) |
8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm) |
| Max Power Consumption |
• 7.93 W (220V / 50Hz with no PD connected)
• 141.40 W (220V / 50Hz with 123 W PD connected) |
| Max Heat Dissipation |
• 27.04 BTU/h (220V / 50Hz with no PD connected)
• 482.17 BTU/h (220V / 50Hz with 123 W PD connected) |
