| Interface |
• 8× 10/100/1000 Mbps RJ45 Ports
• AUTO Negotiation
• AUTO MDI/MDIX |
| Network Media |
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100? STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100? STP (maximum 100m)
• 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100? STP (maximum 100m) |
| Fan Quantity |
Fanless |
| Physical Security Lock |
Yes |
| External Power Supply |
External Power Adapter(Output: 53.5VDC / 1.31A) |
| Packet Forwarding Rate |
11.904 Mpps |
| PoE Ports (RJ45) |
• Standard: 802.3 af/at compliant
• PoE Ports: Ports 1–8
• Power Supply: 65 W |
| Mac Address Table |
4K |
| Jumbo Frame |
16 KB |
| Switching Capacity |
16 Gbps |
| Dimensions ( W x D x H ) |
6.2×4.0×1.0 in (158×101×25 mm) |
| Max Power Consumption |
• 4.59 W (220/50 Hz no PD connected)
• 75.75 W (220/50 Hz with 65 W PD connected) |
| Max Heat Dissipation |
• 15.66 BTU/h (no PD connected)
• 258.46 BTU/h (with 65 W PD connected) |
