| Interface |
• 6× 10/100 Mbps RJ45 Ports (ports 1–4 support 802.3af/at PoE+)
• AUTO Negotiation
• AUTO MDI/MDIX |
| Network Media |
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• EIA/TIA-568 100? STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
• EIA/TIA-568 100? STP (maximum 100m) |
| Fan Quantity |
Fanless |
| Physical Security Lock |
Yes |
| External Power Supply |
External Power Adapter (Output: 53.5 V DC / 1.31 A) |
| Packet Forwarding Rate |
0.8928 Mpps |
| PoE Ports (RJ45) |
• Standard: 802.3 af/at compliant
• PoE Ports: Ports 1–4
• Power Supply: 67 W |
| Mac Address Table |
2K |
| Jumbo Frame |
2 KB |
| Switching Capacity |
1.2 Gbps |
| Dimensions ( W x D x H ) |
6.2 x 4.0 x 1.0 in (158 x 101 x 25 mm) |
| Max Power Consumption |
• 2.52 W (220 V / 50 Hz, no PD connected)
• 75.4 W (220 V / 50 Hz, with 67 W PD connected) |
| Max Heat Dissipation |
• 8.59 BTU/h(no PD connected)
• 257.11 BTU/h(with 67 W PD connected) |
