| Standards and Protocols |
IEEE802.3i, IEEE802.3u, IEEE802.3ab, IEEE802.3af, IEEE802.3at, IEEE802.3bt* |
| Network Media |
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100 m)
EIA/TIA-568 100? STP (maximum 100 m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100 m)
EIA/TIA-568 100? STP (maximum 100 m)
• 1000BASE-T: UTP category 5, 5e, 6 cable(maximum 100 m) |
| Ports |
• 1× 10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps/10 Mbps RJ45 data-in port
• 1× 10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps/10 Mbps RJ45 power+data-out port (Max. 90 W)
• 1× AC socket |
| Power Consumption |
• Input: 100-240 V, 50/60 Hz, 1.6A
• Output: Auto-determine the necessary power requirements (max. 90 W) |
| Basic Function |
• Auto-Sensing Algorithm enables providing power with 802.3af/at/bt* PD
• Auto-determine the necessary power requirements
• Wall-mounting and desktop installation
• Plug-and-Play |
| LED |
Power / PoE |
| Dimensions ( W x D x H ) |
6.1*2.8*1.7 in (155*70*42 mm) |
