General
|
|
Brand
|
Mushkin Enhanced
|
|
Series
|
Vortex
|
|
Model
|
MKNSSDVT512GB-D8
|
|
Type
|
M.2 (2280) Internal Solid State Drive (SSD)
|
|
Used For
|
Consumer
|
|
UPC
|
846651033642
|
|
Physical
|
|
Form Factor
|
M.2 (2280)
|
|
Capacity
|
512GB
|
|
Interface
|
PCIe Gen4 x4 NVMe 1.4
|
|
Controller
|
InnoGrit IG5236
|
|
Height
|
3.8mm
|
|
Width
|
80.0mm
|
|
Depth
|
22.0mm
|
|
Weight
|
7g
|
|
Performance
|
|
Max Sequential Read
|
Up to 6750MB/s
|
|
Max Sequential Write
|
Up to 2635MB/s
|
|
Max 4K Random Read IOPS
|
Up to 200,000
|
|
Max 4K Random Write IOPS
|
Up to 645,000
|
|
MTBF
|
1,500,000 hours
|
|
TBW
|
250TB
|
|
Features
|
|
Features
|
MEDS (Mushkin Enhanced Data-protection Suite) ensures valuable data is protected
|
|
- Built-in LDPC ECC provides the most-powerful data correction level in use today
|
|
- End-to-end data path protection
|
|
- Global wear-leveling evens program/erase counts across data blocks to extend lifespan
|
|
512MB DDR4 DRAM
|
|
SLC caching accelerates burst performance
|
|
L1.2 power mode support for ultra-low power consumption
|
|
NVMe Security Erase support
|
|
NVMe Deallocate function support (NVMe equivalent of TRIM command)
|
|
High-reliability 3D NAND flash
|
|
S.M.A.R.T. support
|
|
User-upgradeable firmware
|
|
Temperature sensor
|
|
RoHS, FCC, CE
|
|
Power Consumption (Idle): 0.1W
|
|
Power Consumption (Active): Up to 7W
|
|
Max sequential speeds and IOPS measured using CrystalDiskMark 8.0.1 x64.
|
|
Environmental
|
|
Operating Temperature
|
0°C-70°C
|
|
Storage Temperature
|
-40°C-85°C
|
|
Max Shock Resistance
|
1500G
|
|
Power Supply
|
3.3V DC
|
