| Form Factor |
M.2 2280 |
| Interface |
PCIe 4.0 NVMe |
| Capacities |
512GB, 1024GB, 2048GB, 4096GB |
| Controller |
Phison E18 |
| NAND |
3D TLC |
| Sequential read/write |
512GB – 7,000/3,900MB/s
1024GB – 7,000/6,000MB/s
2048GB – 7,000/7,000MB/s
4096GB – 7,000/7,000MB/s |
| Random 4K read/write |
512GB – up to 450,000/900,000 IOPS
1024GB – up to 900,000/1,000,000 IOPS
2048GB – up to 1,000,000/1,000,000 IOPS
4096GB – up to 1,000,000/1,000,000 IOPS |
| Total Bytes Written (TBW) |
512GB – 400TBW
1024GB – 800TBW
2048GB – 1.6PBW
4096GB – 3.2PBW |
| Power consumption |
512GB – 5mW idle / 0.34W avg / 2.7W (MAX) read / 4.1W (MAX) write
1024GB – 5mW idle / 0.33W avg / 2.8W (MAX) read / 6.3W (MAX) write
2048GB – 5mW idle / 0.36W avg / 2.8W (MAX) read / 9.9W (MAX) write
4096GB – 5mW idle / 0.36W avg / 2.7W (MAX) read / 10.2W (MAX) write |
| Storage temperature |
-40°C~85°C |
| Operating temperature |
0°C~70°C |
| Dimensions |
80mm x 22mm x 2.21mm (512GB-1024GB)
80mm x 22mm x 3.5mm (2048GB-4096GB) |
| Weight |
512GB-1024GB – 7g
2048GB-4096GB – 9.7g |
| Vibration operating |
2.17G peak (7-800Hz) |
| Vibration non-operating |
20G Peak (20-1000Hz) |
| MTBF |
1,800,000 hours |
| Warranty/Support |
Limited 5-year warranty with free technical support |
