| Form Factor |
2.5" |
| Interface |
SATA Rev. 3.0 (6Gb/s) – with backwards capability to SATA Rev 2.0 (3Gb/s) |
|
256GB, 512GB, 1024GB, 2048GB |
| Controller |
SM2259 |
| NAND |
3D TLC |
| Encrypted |
XTS-AES 256-bit encryption |
|
256GB — up to 550/500MB/s
512GB–2048GB — up to 550/520MB/s |
|
up to 90,000/80,000 IOPS |
| Power Consumption |
0.06W idle / 0.2W avg / 1.3W (MAX) read / 3.2W (MAX) write |
| Dimensions |
100.1mm x 69.85mm x 7mm |
| Weight |
40g |
| Operating temperature |
0°C~70°C |
| Storage temperature |
-40°C~85°C |
| Vibration operating |
2.17G Peak (7-800Hz) |
| Vibration non-operating |
20G Peak (10-2000Hz) |
| Life expectancy |
1 millions hours MTBF |
|
Limited 5-year warranty with free technical support |
|
256GB — 150TB
512GB — 300TB
1024GB — 600TB
2048GB — 1200TB |
