| D-Link DES-1008PA Specifications |
| Product/Performance Specifications |
- MAC Address Table: 1K
- Switch Fabric: 1.6Gbps
- Transmission Method: Store-and-forward
- Packet Buffer Memory: 96KB
|
| Diagnostic LEDs |
- Per Unit: Power / PoE Max
- Per Port: Activity / Link & Speed
- PoE port: Power / Status
|
| Interface Options |
RJ-45: 10BASE-T, 100BASE-TX |
| Network Protocol and Standards |
IEEE: 802.3 Ethernet, 802.3u, 802.3x Flow Control, 802.3af (Power over Data Pairs) |
| Electrical |
- Power Supply: 48V DC/1.25A
- Max Power Consumption: 69 Watts maximum
- PoE budget: Up to 15.4 Watts max per port, for Ports 1-4 Only. 52 Watts Total
|
| Minimum System Requirements |
- Devices Supporting 802.3 Ethernet or 802.3u Fast Ethernet
- CAT5 Ethernet Cable
- RJ-45 port for Each Computer
- CD-ROM Drive to View Product Documentation
|
| Package Contents |
- 8-Port Desktop Switch with 4 PoE Ports
- Power Adapter
- CD-ROM2 with Product Documentation
|
| Operating Temperature |
- Operating: 32° to 104°F (0° to 40°C)
- Storage: 14° to 158°F (-10° to 70°C)
|
| Operating Humidity |
5% ~ 90% RH, Non-condensing |
| Certifications |
|
| Dimensions (W x D x H) |
- Item: 6.8” x 3.9” x 1.1” (172mm x 98mm x 27.9mm)
- Packaging: 10.9” x 8.0” x 2.4” (277.9mm x 204mm x 62mm)
|
| Weight |
- Item: 1 lb (0.5 kg)
- Packaging: 1.4 lbs (0.6 kg)
|
