| D-Link DES-1005P Specifications |
| Number of Ports |
Five 10/100 Mbps Ports including one PoE enabled |
| Switching Capacity |
1Gbps |
| Standards |
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
ANSI/IEEE 802.3 NWay auto-negotiation
IEEE 802.3x Flow Control
IEEE 802.1p QoS |
| PoE Features |
Supports IEEE 802.3af
Supplies up to 15.4 watts of power to PD |
| Data Transfer Rates |
Ethernet:
- 10 Mbps (half duplex)
- 20 Mbps (full duplex)
Fast Ethernet:
- 100 Mbps (half duplex)
- 200 Mbps (full duplex)
|
| Network Cables |
10BASE-T:
- UTP CAT 3, 4, 5/5e (100 m max)
- EIA/TIA-586 100-ohm STP (100 m max)
100BASE-TX
- UTP CAT 5/5e (100 m max.)
- EIA/TIA-568 100-ohm STP (100 m max.)
|
| Media Interface Exchange |
Auto MDI/MDIX adjustment for all ports |
| LED Indicators |
Per port: Link/Activity/Speed/PoE Status
Per device: Power/PoE Max |
| Transmission Method |
Store-and-forward |
| MAC Address Table |
2k Entries per device |
| MAC Address Learning |
Automatic update |
| Packet Filtering/Forwarding Rates |
Ethernet: 14,880 pps per port
Fast Ethernet: 148,800 pps per port |
| RAM Buffer |
64 KBytes per device |
| D-Link Green |
IEEE 802.3az Energy Efficient Ethernet (EEE)
Link status detection power saving
Cable length detection power saving |
| Power Inputs |
Switching 48 V/0.5 A Level V power adapter |
| Power Consumption |
Power On (Standby):
DC input: 0.9 watt
AC input: 1.8 watts
Maximum (PoE Off):
DC input: 2.05 watts
AC input: 2.7 watts
Maximum (PoE On):
DC input: 17.29 watts
AC input: 20.2 watts |
| MTBF |
324,616 hours |
| Operating Temperature |
32 to 104 °F (0 to 40 °C) |
| Storage Temperature |
104 to 158 °F (-40 to 70 °C) |
| Storage Humidity |
0% to 95% RH non-condensing |
| Dimensions |
5.5 x 3.3 x 1.1 inches (140 x 85 x 28 mm) |
| Certifications |
FCC Class B
ICES-003 Class B
cUL |
