| D-Link DES-1024D Specifications |
| Standards |
- IEEE 802.3 10BASE-T Ethernet (twisted pair copper)
- IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
- ANSI/IEEE 802.3 NWay auto-negotiation
- IEEE 802.3x flow control
|
| LAN |
- IEEE 802.3 10BASE-T
- IEEE 802.3u 100BASE-TX compliance
- IEEE 802.3x Flow Control support
|
| Data Transfer Rates |
- Fast Ethernet
- 100 Mbps Half-Duplex
- 200 Mbps Full-Duplex
- Ethernet
- 10 Mbps Half-Duplex
- 20 Mbps Full-Duplex
|
| Switching Capacity |
4.8 Gbps |
| Number of Ports |
24 10/100Mbps Fast Ethernet ports |
| Network Cables |
- 10BASE-T:
- UTP CAT 3/4/5/5e (100 m max.)
- EIA/TIA-586 100-ohm STP (100 m max.)
- 100BASE-TX:
- UTP CAT 5/5e (100 m max.)
- EIA/TIA-568 100-ohm STP (100 m max.)
|
| Media Interface Exchange |
Auto MDI/MDIX adjustment for all ports |
| LED Indicators |
|
| Transmission Method |
Store-and-forward |
| MAC Address Table |
8K entries per device |
| MAC Address Learning |
Automatic update |
| Packet Filtering /Forwarding Rates |
- Ethernet: 14,880 pps per port
- Fast Ethernet: 148,800 pps per port
|
| Topology |
Star |
| Protocol |
CSMA/CD |
| Dimensions |
11.0 x 5.0 x 1.7 inches(280 x 125.8 x 44 mm) |
| Weight |
3.652lbs(1.66kg) |
| Power Consumption |
- Power On (Standby):
- DC input: 1.33 Watts
- AC input: 2.39 Watts
- Maximum:
- DC input: 5.50Watts
- AC input: 8.07Watts
|
| Heat Dissipation |
- Power On (Standby):
- Maximum:
|
| MTBF |
810,880 hours |
| Temperature |
- Operating: 32 to 104 °F (0 to 40 °C)
- Storage: 14 to 158 °F (-10 to 70 °C)
|
| Humidity |
- Operating: 10% to 90% non-condensing
- Storage: 5% to 90% non-condensing
|
| Certifications |
- CE
- FCC
- ICES-003
- C-Tick
- cUL
- CB
|
