Model
TUF Gaming GT302 ARGB
Case Size
Mid Tower
Motherboard Support
EATX (12"x10.9")
ATX
Micro-ATX
Mini-ITX
Drive Bays
2 x 2.5" Bay
2 x 2.5"/3.5" Combo Bay
Expansion Slots
8
3 (additional vertical)
Front I/O Port
1 x headphone / Microphone
2 x USB 3.2 Gen1
1 x USB 3.2 Gen 2x2 Type C
Tempered Glass
Left Side
Radiator Support (Front)
140 mm
280 mm
Radiator Support (Top)
120 mm
140 mm
240 mm
280 mm
360 mm
Radiator Support (Rear)
120 mm
140 mm
Cooling Support (Front)
3 x 140 mm
Cooling Support (Top)
3 x 120 mm
3 x 140 mm
Cooling Support (Rear)
1 x 120 mm
1 x 140 mm
Pre-installed Fans (Front)
3 x 140 mm
PWM
ARGB
Pre-installed Fans (Rear)
1 x 140 mm
ARGB
Maximum CPU Cooler Height
165 mm
Maximum GPU Length
407 mm
Maximum PSU Length
220 mm
Removable Dust Filters
Front
Top
Bottom
Maximum Cable Management Space
37 mm
Dimensions
235*520*485 mm (W*H*D)
BTF motherboard compatible
Yes
